| Thread Size | Ball Dia. | Overall Length | Stem Dia. | Effective Length | Order No. | Model |
|---|---|---|---|---|---|---|
M3 | 3.0 | 50 | 2.0 | 42.5 | 90040-30-50-3 | YK-A-5003-0067 |
| 4.0 | 2.0 | 46.0 | 90040-40-50-3 | YK-A-5003-0068 | ||
| 5.0 | 2.5 | 50.0 | 90040-50-50-3 | YK-A-5003-0069 | ||
| 6.0 | 75 | 4.0 | 75.0 | 90040-60-75-3 | YK-A-5003-4785 | |
| 8.0 | 4.0 | 75.0 | 90040-80-75-3 | YK-A-5003-4786 | ||
| 10.0 | 4.0 | 75.0 | 90040-100-75-3 | YK-A-5003-7057 | ||
| 6.0 | 100 | 4.0 | 100.0 | 90040-60-100-2 | YK-A-5003-4861 | |
| 8.0 | 4.0 | 100.0 | 90040-80-100-2 | YK-A-5003-4863 | ||
| 10.0 | 4.0 | 100.0 | 90040-100-100-3 | YK-A-5003-7056 | ||
| 12.0 | 4.0 | 100.0 | 90040-100-100-3 | YK-A-5003-7445 | ||
| 10.0 | 150 | 4.0 | 150.0 | 90040-100-150-3 | YK-A-5003-7055 | |
| 12.0 | 4.0 | 150.0 | 90040-120-150-3 | YK-A-5003-7446 | ||
| 10.0 | 200 | 4.0 | 200.0 | 90040-100-200-3 | YK-A-5003-7054 | |
| 12.0 | 4.0 | 200.0 | 90040-120-200-3 | YK-A-5003-7447 |
